Fluke 750R27 Reference Pressure Module

Overview Fluke 750R27 Reference Pressure Module

Fluke 750R27 Reference Pressure Module is a reference pressure module for compatible Fluke calibrators. It is intended for use with Fluke 740/750 and compatible 720/710 series calibrators. Specified range: 0 to 20 bar with accuracy 0.015% total uncertainty.

Features and Performance

• 0 psi to 300 psi (0 to 20 bar), (0 to 2000 kPa)
• Compatible Media: Type 316 Stainless Steel
• Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
• Rugged urethane molded case protects the module from rough handling and harsh conditions
• Features internal temperature compensation from 32 °F to 122 °F for full-accuracy performance
• Includes NIST-traceable calibration certificate
• Module can be used with any of the Fluke 740, 750 or compatible 720 or 710 series calibrators
• Reference class modules have a 0.015% total uncertainty
• Module has its own serial number to maintain independent traceability
• Includes an adapter set with each module
• 3-year warranty
• NIST-Traceable Calibration Certificate
• Adapter Set with Each Module

Why Choose This Product

This model fits calibration workflows that need a defined pressure range and a module matched to compatible instruments. The compatibility information in the source data points to use with Fluke 740/750 and compatible 720/710 series calibrators. It is relevant when the application specifically calls for 0 to 20 bar.

Product Specifications
