Fluke 750RD5 Reference Pressure Module

Overview Fluke 750RD5 Reference Pressure Module

Fluke 750RD5 Reference Pressure Module is a reference pressure module from Fluke. It is intended for pressure measurement and calibration workflows where a defined module range and compatible connection to the host instrument are required. The listed configuration includes a -15 PSI to 30 PSI (-1 to 2 bar), (-100 to 200 kPa) range and Dry media compatibility.

Features and Performance

• Range: -15 psi to 30 psi (-1 to 2 bar), (-100 to 200 kPa)
• Compatible Media: Dry
• Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
• Rugged urethane molded case protects the module from rough handling and harsh conditions
• Features internal temperature compensation from 32°F to 122°F for full-accuracy performance
• Includes NIST-traceable calibration certificate
• Module can be used with any of the Fluke 740, 750 or compatible 720 or 710 series calibrators
• Reference class modules have a 0.015% total uncertainty
• Module has its own serial number to maintain independent traceability
• Includes an adapter set with each module
• 3-year warranty

Included items listed in the source data:

• NIST-Traceable Calibration Certificate
• Adapter Set with Each Module
• 3-year warranty

Why Choose This Product

This module is best selected by matching the required pressure range and media specification to the target calibration setup. It is relevant when maintaining traceability and using a dedicated module format are important to the workflow. The stated range is -15 PSI to 30 PSI (-1 to 2 bar), (-100 to 200 kPa).
